Description
Short Description & Specifications
| Connection | 1/4″ to 2″ Threaded Inner Dia, Flange Type |
|---|---|
| Measuring Medium | Lubricating oil, diesel, hydraulic fluid, syrup, pitch, honey, sulfuric acid, hydrofluoric acid & high-viscosity liquids |
| Accuracy & Repeatability | ±0.5% (Reading Value, 1:20 range), ±1% (Full Range) | Repeatability: 0.1% |
| Flow Range | 0.6 to 20,000 L/h (0.0006 to 20 m³/h) |
| Working Temperature | Standard: -40°C ~ +80°C | High-Temp Type: up to +200°C |
| Working Pressure | Std. 16 bar (High-Pressure Customize Opt. Available) |
| Body & Gear Material | Std. Stainless Steel |
| Medium Viscosity | 5 to 500 mm²/s (cSt) |
| Output & Communication | Pulse, 4-20mA, Modbus RS485/RS232, HART, GPRS |
| Protection & Explosion Grade | IP65 | Explosion Grade Exdllct6Gb |
Features & Key Advantages
High Precision & Repeatability
Delivers reading accuracy of ±0.5% with 0.1% repeatability for accurate volumetric flow tracking.
High Viscosity & Corrosive Capability
Handles challenging media including highly viscous fluids (syrup, pitch) and aggressive acids (sulfuric, hydrofluoric).
Wide Thermal Limits
Operates effectively under severe temperatures with custom modifications supporting cryogenic to high-heat ranges (-196°C to +200°C).
High Pressure Resistance
Built to with stand up to 16 bar standard on stainless steel models, expandable to 100 bar for high-pressure systems.
Intelligent Sensor Configurations
Supports basic pulse output, analog transceivers, and intelligent 4-button LCD digital display units with alarm relay control.
Easy Protocol Integration
Seamlessly integrates into automated control systems via Modbus RTU (RS485), HART, Bluetooth, and GPRS communications.
