Description
Remote & Central Monitoring Specifications
| System Architecture | Cloud-hosted IoT platforms, On-Premise Central SCADA Server, Remote Terminal Units (RTU), Cellular/Satellite Data Gateways, and Edge Gateways. |
|---|---|
| Monitored Parameters | Effluent Quality (COD, BOD, TSS, pH), Flow Rates, Pump Run Status, Water Tank Levels, Power Consumption, Temperature, Pressure, Gas Levels. |
| Communication Modes | Cellular: 4G LTE / 5G / NB-IoT / GSM Wireless: Wi-Fi, LoRaWAN, Zigbee Wired: Ethernet (TCP/IP), RS485 Serial (Modbus) Transmission Frequency: Real-time streaming or user-set intervals (1 sec to 60 min) |
| Platform Capacity & Access | Connected Devices: Up to 10,000+ remote nodes Concurrent Users: Unlimited multi-user access levels Supported Clients: Web Browsers (Chrome/Edge), iOS App, Android App, Desktop Software Data Retention: Cloud storage up to 5+ years |
| Power Options | 100-240 VAC, 12-24 VDC, Solar Panel with Battery Backup, or High-Capacity Lithium Standby Power |
| Cybersecurity Measures | SSL/TLS Encryption, AES-128/256 Data Security, Two-Factor Authentication (2FA), Role-Based Access Control (RBAC) |
| Notification & Alarm Methods | SMS Alerts, Email Notifications, WhatsApp Push Messages, Web Dashboard Pop-ups, Audible Horn/Beacon Outputs |
| Operating Conditions | Operating Temp: -20 °C to 70 °C | Humidity: Up to 95% RH non-condensing |
| Enclosure Protection | IP67 / NEMA 4X Weatherproof Field Gateway Enclosures |
| Other Specifications | DoE/DoE Online Server Integration Support, Offline Data Buffering, Interactive GIS Map Dashboard View |
Features & Key Advantages
Anytime, Anywhere Access
Check plant performance and live sensor readings from any computer, tablet, or smartphone using a web browser.
Instant SMS & Email Alarms
Receive immediate alert notifications when parameters cross safe limits to stop problems before failure happens.
Regulatory Compliance Ready
Designed to automatically stream water quality and discharge data directly to central environmental monitoring servers.
Multi-Site Centralization
Connect and monitor dozens of remote plants, WTPs, or ETPs in different locations from a single dashboard screen.
No Data Loss Protection
Field gateways store data locally during network outages and automatically upload it as soon as connection recovers.
Secure Cloud Storage
Encrypted data transmission keeps your operational records safe and easily downloadable for trend analysis.
